Hinges for glass doors SIMONSWERK VG 3990 K
Product code
MB00008832
All prices include VAT
From
€77.91
From
€77.91
Only %1 left
Hinges for glass doors SIMONSWERK VG 3990 K
Manufacturer - SIMONSWERK (Germany)
Manufacturer - SIMONSWERK (Germany)
-
- knuckle length: 95 mm
- knuckle diameter: 18 mm
- material thickness: 3,5 mm
- suitable for wooden and casing frames
- max load: 60 kg (2 hinges per leaf)
- for glass doors with a glass thickness of 8 and 10 mm
- torsion-proof pin
- concealed, maintenance-free axial-radial slide bearings
- compatible with receivers VARIANT V
- material: stainless steel
All prices include VAT
- Products
- Price
- In Stock
- Quantity
-
Glass door hinge VG 3990 K, stainless steel, leftCode: SB00008855Art. Nr.: 5 320503 2 04002Price:From €77.91In Stock: 0 pc. -
Glass door hinge VG 3990 K, stainless steel, rightCode: SB00008854Art. Nr.: 5 320503 1 04002Price:From €77.91In Stock: 0 pc.
| Manufacturer | SIMONSWERK |
|---|---|
| hinge type | heavy duty hinge |
| hinge shape | rectangular |
| door construction | for rebated doors |
| door direction | when ordering please indicate door swing direction |
| class as per EN 1935 | not certified |
| fire safety | not suitable for fire and smoke safety doors |
| glass thickness | 8-10 mm |
| distance between centres of lugs | 22 mm |
| lug diameter | Ø7 mm |
| lug length | 60 mm |
| lug amount | 2 |
| material thickness | 3.5 mm |
| leaf material | for glass doors |
| load capacity | middle |
| leaf maximum weight | 60 kg |
| suitable for aluminium frames | not suitable |
| suitable for steel frames | not suitable |
| suitable for industrial frames | suitable using additional mounting parts |
| suitable for timber frames | suitable |
| anti-corrosion resistance | not certified |
| adjustment | not adjustable |
| groove for leaf seal | no |
| anti-intruder protection | no |
| knuckle length | 95 mm |
| knuckle diameter | 18 mm |
| spindle diameter | 9 mm |
| height | 95 mm |
| maintenance | not required (self-lubricating bearings) |
| installation template | available for sale or rent |
| material | steel / stainless steel |
