Handle for lift/slide casements FSB 34 1289 ALU
Product code
MB00009267
All prices include VAT
From
€552.37
From
€552.37
Only %1 left
Questions and answers
Aluminium handle for lift/slide casements FSB 34 1289
Manufacturer - FSB (Germany)
Design: Markus Michalski and Michael Schmidt
Model 1289 boasts contemporary and minimal aesthetics. Its elegant and nuanced lines at the front of the handle are a delight to the eye, while the well-proportioned curvature on the inside ensures comfortable and ergonomically soft gripping.
Catalogue
Manufacturer - FSB (Germany)
Design: Markus Michalski and Michael Schmidt
Model 1289 boasts contemporary and minimal aesthetics. Its elegant and nuanced lines at the front of the handle are a delight to the eye, while the well-proportioned curvature on the inside ensures comfortable and ergonomically soft gripping.
-
- suitable handle for balcony doors and facade sliding systems with parallel lift/slide mechanisms
- stop-in positions at 90° and 180°
- with concealed one-side or connecting fastening
- screws: M6 x 80 mm
- spindle square: 10 mm
- with profile cylinder hole or without locking option
- handle length: 252 mm
- backplate size: 155 x 35 mm
- with PZ keyhole or without keyhole
- centre distance for PZ backplate: 69 mm
- distance from casement surface to outer edge of handle: 70 mm
- distance between screws: 80 mm (suitable for Siegenia HS window hardware)
- material: aluminium anodised, textured matt
- available finishes:
-
-
- F1 natural aluminium tone
- S5 medium dark bronze tone blasted
- S7 dark bronze tone blasted
- S8 black blasted
- powder coated in black RAL9005
- powder coated in white RAL9016
-
Catalogue
All prices include VAT
- Products
- Price
- In Stock
- Quantity
-
FSB 34 1289 handle for lift/slide casements, interior, BAC, aluminium black S8Code: SB00020748Art. Nr.: 0 34 1289 01102 0810Price:From €552.37In Stock: 0 pc.
| Manufacturer | FSB |
|---|---|
| material | aluminium anodised blasted |
| purpose | for sliding/lift-up balcony doors and facade leaves |
| installation type | one-sided / connecting |
| fastening type | covered |
| installation type | screw on |
| locking function | PZ / BAC |
| handle used for | for leaf sliding |
| function | locking / non-locking |
| rose type | standard |
| backplate/rose shape | oval |
| shape | L-shape |
| handle length | 252 mm |
| backplate/rose size | 35 x 155 mm |
| stop-in positions | 90° |
| fastening centre distance | 80 mm |
| distance from leaf surface to outer edge of handle | 70 mm |
| backplate/rose thickness | 14 mm |
| handle square spindle size | 10 mm |
